Rollover Truck Wash Machine

The Rollover Truck wash machine is designed to facilitate the cleaning of both trucks and buses. Unlike traditional car wash machines, this particular model has been specifically designed to accommodate larger vehicles. The system comprises 3-5 set of brushes that rotate around the vehicle as it passes through the wash tube. With this innovative design, the Rollover Truck/Bus wash machine ensures that every inch of the vehicle is cleaned thoroughly.

Product Feature:

1.Computerized automatic control system, high degree of automation,
2.Complete functions, easy operation, beautiful appearance, energy saving and environmental protection, long service life,
3.Low cost of car washing, low maintenance cost, strong anti-embroidery performance and good reliability.
4.Automatic induction spraying system, automatic siphon foam system, automatic current control system, automatic detection and alarm system, automatic model identification,
5.Emergency stop protection device, sub-action technology, remote control, winter anti-freeze technology, intelligent

Product display

Truck Wash Machine Advantages

  • Fast car washing, high degree of automation, safety and convenience, and the car washing operation can be automatically completed without manual work;
  • The machine is composed of the whole machine frame, water circuit, electricity circuit, air circuit, cleaning and maintenance spraying system, conveyor, unique strong fixed air drying system, international general brush, industrial automation PLC control system configured with foreign brand electronic components, etc,
  • The appearance design is novel. The overall frame of the machine is first treated with high temperature phosphating and hot-dip galvanizing, and then the surface is powder painted, which is corrosion-resistant and rust-proof.
  • Unique environmental protection and water-saving system, new touch-type operation display screen, simple and easy to understand, human-machine dialogue is realized through intuitive touch screen, and automatic fault detection system makes the equipment more safe and reliable
  • The actual use cost is low, the work efficiency is more than 5 times that of the traditional manual car wash, and it has impeccable functional advantages.

Truck Wash Machine Specification:

ModelTruck wash Machine R3Truck wash Machine R5
Machine Size (m)L*W*H: 2500*4500*5500mmL*W*H: 4500*4500*5500mm
Max. Car Size (m)L*W*H: 12000* 3000*4500mL*W*H: 12000* 3000*4500m
Installation Size (m)L*W*H: 18000*6500*5700mmL*W*H: 21000*6500*5700mm
Suitable Wahing modeVarious types of Bus, Truck, Train carriage etc.Various types of Bus, Truck, Train carriage etc.
Wash Time3-5 minutes per vehicle3-5 minutes per vehicle
Water Consumption150L-200L per vehicle150L-200L per vehicle
Foam Consumption25-30ML per vehicle25-30ML per vehicle
Electricity Consumption0.5KWH per vehicle0.5KWH per vehicle
Machine Power10 KW11 KW
Power Supply3-phase,5 wires 380V/50HZ3-phase,5 wires 380V/50HZ
Average washing quantity1 5-20 vehicles/ hour1 5-20 vehicles/ hour
Top Brush11
Big Vertical Brush22
Skirt Brush2

Details:

Integrated intelligent induction system

Dense photoelectric layout, forming a comprehensive induction network and accurately collecting vehicle parameters; Intelligent call, real-time adjustment of follow-up car washing parameters, to achieve precise avoidance and no dead angle ultra clean cleaning effect.

Human-machine interface: intelligent operation, unattended, this is the future choice

Human-machine interface: intelligent operation, unattended, this is the future choice

Function: touch screen operation, man-machine interface Features: Independent operating platform, made of plastic mold, sunscreen and waterproof, with 14-inch touch screen, support credit card, coin and APP payment.

PLC control system

PLC control system

Germany SIEMENS famous brand, the system is stable, with low failure rate, long life time

EVA soft brush

EVA soft brush

Brush self-cleaning technology, no water, no dust, no sand, not easy to deform, soft without damaging car paint

Big power fan drying motor

Big power fan drying motor

which can automatically adjust the air drying power according to the vehicle model, reducing power consumption and saving energy under the condition of ensuring the air drying rateof more than 95%. The main body of the fan adopts turbine type, with noise reduction of more than 60%

SITI water proof motor reducer

SITI water proof motor reducer

Italy SITI international brand,fully enclosed integrated design,waterproof grade IP68,life time is more than 20 years

PEPPERL+FUCHS sensor

PEPPERL+FUCHS sensor

Germany P+F international brand, waterproof level IP69K, accurately measure the car driving distance, predict the car location

Stainless steel pipe & nozzles

Stainless steel pipe & nozzles

Using high pressure fan drying motor, high wind speed, high pressure, to achieve rapid fan drying effect, perform segmented and powerful fan drying on the whole car;

Whole plate guidance system

Integrated whole plate guidance system, automatic left and right adjustment. Rough entry, accurate guidance. Widen the conveying track, adapt to widen the tire and extend the cleaning range. quenched galvanized track system, continuous water operation, lasting bright luster.

Foam wax system

Environmental protection foam liquid: it is developed with ingenuity, decontamination and descaling, only for the safety and cleaning of car paint Coating bright wax: hydrophobic and bright, giving your car a visible protective film. Lasting care, more than three days, bright effect

SHINEWASH Prodution Workshop

Quality & Control

  • Component traceability
  • Component quality inspection
  • Detection before installation
  • Complete machine test

Certification

SHINEWASH Customer Visit

Our Services

 Guarantee period: 3 years( 100,000 times), in guarantee period, if the machine have any question, we could provide the parts free of charge.

Shinewash car washing machine after-sales service

Pre-sale service:

Our professional engineer could help you draw design drawings and installation drawings, so that you can save a lot of complicated processes

Parts service: ​

We will provide enough spare parts when shipment, such as nozzels, bearing, seals, walking wheels and so on.

After-sale service:

When the machine has any question when using, we could guide you exchange the parts by video, until get better. If necessary, we could send the professional after-sales team to your shop and repair it.

Customized service:

Our car wash machine could be customized, such as main component, appearance, color, logo and so on.
